Is it possible to fix laptop memory slot failure with a guitar pick? Yes, it is. You will not fix the memory slot itself, but you can work around the problem. 🙂
Today I received a Toshiba Satellite Pro 4600 laptop with the following complaint:
I recently bought some DDR2 667 MHZ RAM for My ASUS M2R32 motherboard. I went to put the ram in, booted up, and checked the memory. Odd, it wasn't reading the new ram. So I took out all the ram, replaced my old ram slot with one of my new sticks, and the system worked perfectly. The same with the other new slot. So, I moved the old RAM to a different slot and, surprise, no post! RAM Slots on a Laptop. RAM slots on a laptop are significantly different than on a desktop PC. Because the form factor of a laptop precludes the desktop orientation where the memory is perpendicular to the motherboard, the RAM slides into slots that allow it to be parallel to the motherboard once installed.
The laptop starts and works properly, but recognizes only one of the two memory modules installed. The laptop has two 256MB RAM modules installed, but registers only 256MB.
First of all, I removed the memory cover to find out if both memory modules are installed correctly. The laptop had two 256MB Kingston modules installed and they were seated properly.
When I started the laptop and entered the BIOS setup menu, I found that only one of the two memory modules is detected and the laptop registers only 256MB (262144KB) of RAM instead of 512MB (524288KB).
Just a side note. In the computer world 1MB=1024KB. That’s why 256MB=262144KB and 512MB=524288KB.
I tried reseating both memory modules but it didn’t help.
After that I tried installing both memory modules in both memory slots one by one and here’s what I found. The laptop worked absolutely fine when both memory modules were installed into the slot A, but failed to boot with both memory modules installed into the slot B.
Apparently, there is nothing wrong with the memory modules and the laptop has a faulty memory slot B. The memory slot is permanently soldered on the motherboard. If one of the slots fails you’ll have to replace the whole motherboard or use the laptop with only one working slot.
Buying a new motherboard for this older laptop wouldn’t make any sense because it’s too expensive, but the laptop is still in a good working condition except the faulty memory slot B, so I continued playing with that trying to find the solution.
I noticed that the laptop start normally with the memory module installed into the faulty slot if I slightly press on the module with my thumb. And this gave me an idea.
This guitar pick is going to fix my laptop. 🙂
I installed both RAM modules back into the slots and then placed the guitar pick over the module in the slot B as it shown on the picture.
I thought if I close the RAM door it will press on the guitar pick/memory module and it will have the same effect as pressing on the module with my thumb. And it worked!
Both memory modules were detected properly and the laptop registered all 512MB. After “the fix” I tested memory with Memtest86+ and the laptop passed the test.
I wouldn’t call it the best solution for fixing a faulty memory slot but in some cases it will work.
By the way, I didn’t charge the customer for this “repair”, he knows what is going on and how I “fixed” his problem.
Bad Ram Slot Symptoms
sfbayzfs
Active Member
Bad Ram Slot On Motherboard
I have a lot of system building experience, and generally held the belief that bad RAM slots on motherboards are uncommon. The first one I encountered was a couple of years ago - I opened up a brand new ITX celeron board and I eventually discovered that one of the RAM slots was bad. The motherboard wouldn't boot with any RAM installed in one of the two RAM slots on the motherboard - remove RAM from that slot, and the system booted fine with RAM in the other slot only. (Of course I had been storing the board for long enough that it was out of warranty, but that's another story...) I suspected a bad solder joint or tin whisker somewhere on the bad RAM slot, but my soldering iron was misplaced a while ago, and a visual inspection of the underside of the board looked OK.Bad Ram Slot Error
I have been testing more boards than I used to over the past year, and I have found a number of other boards which have bad RAM slots, so I was wondering how many bad RAM slots others here have run into on otherwise good motherboards.
Also, has anyone ever successfully fixed a bad RAM slot, say with a solder reflow?
So far, in terms of failure modes with bad RAM slots, either any RAM in that slot is not recognized and ignored, or else the system won't boot with any RAM in that slot, either locking up during POST or black screen before POST, sometimes with beeps. Any time I have had memtest rack up errors, I have eventually traced it to an actual bad stick of RAM, but has anyone else noticed bad RAM slots causing other symptoms?
On dual processor Xeon boards I have further findings:
- If the blue (primary) RAM slot in a channel is bad, that whole channel is unusable
- If the first blue slot for a CPU is bad, that CPU socket is unusable
- If a non-blue slot is bad, usually only that slot is bad
